Truck Unit

T-1100X

High capacity, low cost of ownership

High cooling capacity — best in class
Biofuel-compatible GreenTech engine
Extended 2 000 h maintenance interval (EMI 2000)
Sustainable construction, low refrigerant GWP
Full TracKing connectivity ready

The T-1100X delivers capacity at lower operating speeds and enables precise temperature control. Low operating and maintenance costs together with fuel-saving technology keep total cost of ownership to a minimum. Available in 1- and 2-temperature configurations.

Specifications

Refrigeration Capacity

Capacity on engine power, 0°C: 11 090 W
Capacity on engine power, −20°C: 5 900 W
Capacity on electrical stand-by (evaporator), 0°C: 8 220 W
Capacity on electrical stand-by, −20°C: 4 430 W

Heating Capacity

Capacity on engine power (20°C / −18°C): 6 000 W

Airflow

Airflow HSD: 3 720 m³/h
Independent from unit engine speed: ✓

Weight

Total Unit Weight (50 Model): 473 kg
Whisper option: +17 kg

Unit Dimensions

Height (Whisper option 704 mm): 692 mm
Width: 1 888 mm
Depth: 919 mm

Engine

Displacement: 3,16 L
Maintenance interval (EMI 2000): 2 000 h
Biofuel compatible: ✓

Electrical Stand-by Motor

Voltage / Phase / Frequency: 400/3/50 · 230/3/50 · 230/3/60
Rating: 8,2 kW

Noise

Sound Power Level HSD: 97 dB(A)
Sound Pressure Level HSD: 71,7 dB(A)
Sound Pressure Level LSD: 65,6 dB(A)
Sound Pressure Level Stand-by: 62,5 dB(A)

Refrigerant

Refrigerant: R-452A
Charge: 2,9 kg
GWP / kg: 2 140
Total GWP: 6 206

The technical data and dimensions shown are indicative and not binding. Verify the final dimensions and specifications with our sales team before ordering. Subject to technical changes, errors and translation errors.

More about the TX-Series

+17 %

Cooling capacity

−21 %

Refrigerant GWP

2 000 h

Service interval

−60 %

Operating noise (Whisper)

Flexible. Reliable. Efficient.

The TX-Series is up to 40 kg lighter than its predecessor while delivering up to 17% more cooling capacity and 7% better fuel efficiency. New refrigerant coils and piping reduce the refrigerant charge and GWP by up to 21%, and Whisper technology cuts operating noise by up to 60% — enabling access to noise-sensitive areas.

GreenTech engine and biofuels

Every TX-Series unit is fitted with Thermo King's new GreenTech engine — NRMM Stage V compliant and compatible with HVO/XTL and B100 biofuels. HVO/XTL cuts greenhouse-gas emissions by up to 90 %, and B100 (EN-14214) reduces carbon emissions by up to 60 % and particulates by up to 80 % — all without compromising maintenance intervals.

TSR and TSR-3 controllers

The new TSR and TSR-3 displays are designed for the driver — an intuitive LED screen, symbol-based instructions and colour-coded controls remove language barriers. Cycle-Sentry™ mode, door switch inputs and the Remote Watch diagnostic service keep fuel use and downtime to a minimum, while TouchLog and TracKing compatibility provide full load monitoring throughout the journey.

Quality you can rely on

The TX-Series has undergone years of extensive testing in the harshest conditions — every unit delivers unmatched reliability, operating economy and performance. The Poly-V stretch belt extends belt life, the GreenTech engine is biofuel compatible, the EMI 2000 service interval reaches 2 000 hours or 24 months, and the industry-standard compressor has millions of field operating hours behind it.
