E-1600e

The electric unit your truck can't resist

ElectricTruck

100 % electric — 100 % compatible (electric truck + combustion engine, diesel / gas)
Highest cooling capacity in its class — for large boxes
Built for multi-drop routes with many door openings
Lean design — low-height cabs and access to height-restricted zones
PIEK compliant (Whisper Pro) — access to noise-sensitive areas
Available in single- and multi-temperature (Spectrum) configurations

One product family for every drivetrain — full-electric, diesel and gas vehicles. The unit connects to the electric truck's ePTO (electrical Power Take-Off), which can be either DC or AC. Seamless communication with the vehicle and stepless power control deliver class-leading energy efficiency and the most precise temperature control. Available in 1- and 2-temperature configurations.

Specifications

Refrigeration Capacity

Capacity High Speed, 0°C: 15 430 W
Capacity High Speed, −20°C: 9 470 W
Whisper Pro, 0°C: 11 000 W
Whisper Pro, −20°C: 6 900 W

Heating Capacity

Heating 18°C / −18°C: 12 000 W

Airflow

Airflow: 4 240 m³/h
Independent from unit engine speed: ✓

Weight

Total Unit Weight (50 Model): 315 kg
Without electric stand-by: 280 kg
Alternator (ICE vehicles only): 60 kg

Unit Dimensions

Height: 612 mm
Width: 2 142 mm
Depth: 563 mm

Power source

Drive type: Fully electric
BEV compatibility: High-voltage DC ePTO
ICE compatibility: Alternator
Variable speed: Variable Speed system

Noise

Sound Pressure Level HSD: 63,9 dB(A)
Sound power level HS / Stand-by: 91 dB(A)
Sound power level Whisper Pro: 62 dB(A)

Refrigerant

Refrigerant: R-452A
Charge: 4,5 kg
GWP / kg: 1 945
Total GWP: 8 753

Application range

Vehicle size class: 7,5–26 t
Application: Large trucks, multi-drop distribution, urban areas
Spectrum configurations: E-2, E-3, E-4 (E-2 + E-2)

The technical data and dimensions shown are indicative and not binding. Verify the final dimensions and specifications with our sales team before ordering. Subject to technical changes, errors and translation errors.

More about the E-Volution range

−45 %

CO₂ emissions vs. diesel (LCA)

0 g

Direct emissions in use

7,5–26 t

Compatible truck class

BEV + ICE

Power sources

E-Volution — a new standard for electric truck refrigeration

E-Volution is a high-capacity, all-electric refrigeration solution for rigid trucks in the 7.5–26 t class. Validated compatibility across leading BEV platforms and ICE trucks offers a clear electrification path without retiring existing fleet. Available in both single- and multi-temperature configurations.

High-voltage DC straight from the BEV ePTO

E-Volution's high-voltage DC system connects directly to the ePTO of a BEV truck without AC-conversion losses. The variable speed design optimises power use and minimises impact on the vehicle's range. On ICE trucks the alternator powers the unit — one design, two power sources.

Quiet operation and access to low-emission zones

The variable speed system supports both automatic and driver-operated noise control, enabling early morning, late evening and residential-area deliveries. Zero-emission operation provides access to LEZ, ZEZ and PIEK zones that diesel units are increasingly locked out of.

Fewer parts, less maintenance, more uptime

A lean design with fewer moving parts cuts wear and maintenance needs — the unit stays in productive service for longer. An independent Life Cycle Assessment shows up to 45 % CO₂ reduction versus diesel refrigeration.
