MBB C 750 L
A proven and versatile tail lift with a robust two-cylinder lifting mechanism
750 kg
Lifting capacity
2 100 mm
Platform width
1 450 – 1 700 mm
Platform length
199 kg
Dead weight (from)
A cantilever tail lift for small trucks up to 6.5 t with a robust two-cylinder lifting mechanism. Modular mounting plates are interchangeable with the MBB C 750 S model — the same chassis fits multiple configurations, simplifying inventory management and maintenance. AluLite 30 aluminium platform and Q8 Heller T15 hydraulic oil ensure reliable daily operation.
Stable two-cylinder mechanism
A torsion-resistant mechanism ensures even, parallel movement — a reliable choice for daily distribution work.
Mounting plates interchangeable with C 750 S
Bolt-on mounting plates interchange with the C 750 S — one chassis fits two configurations and simplifies your fleet.
AluLite 30 platform as standard
Lightweight aluminium platform with a slip-resistant cross-milled surface (R10), warning lights and flags — standard across all configurations.
Technical Specifications
The cranes shown in the brochure may be partly equipped with optional equipment and do not always correspond to the standard versions. Country-specific regulations must be observed. Dimensions may vary. Subject to technical changes, errors and translation errors.
Technical Drawing
Standard Features & Technology
Robust lifting mechanism
A durable mechanism with one lifting and one tilting cylinder, one-part underrun protection device and Q8 Heller T15 hydraulic oil. All steel components are KTL-coated as standard for corrosion protection.
Light aluminium tail lift platform
The AluLite 30 aluminium platform combines high stability with low weight. Cross-milled slip-resistant surface (R10), warning lights and flags as standard.
Comfortable operation as standard
Equipped with Slim Control Panel (Basic) featuring an ergonomic button layout and flexible installation for intuitive, safe operation.
MBB CONTROL control system
Modern programmable circuit board with diagnostic capability. The board is protected by double encapsulation to prevent oxidation.
Bolt-on mounting plates
Modular bolt-on mounting plates are interchangeable between MBB C 750 L and C 750 S — simplifies inventory and increases availability.
Optional Features
Stabilisers
Hydraulic or mechanical stabilizers increase stability during loading and minimize vehicle movement.
AluPlan folding platform
Horizontally folding platform for special applications — emergency services and dedicated operations.
Tail lift platform surface options
Standard cross-milling (R10). Also available with double cross-milling or synthetic coating for quieter, low-maintenance operation.
Protective equipment
Stainless steel caps and protective bars prevent impacts and component damage.
MBB SafeClose
Intelligent obstacle detection that stops movement automatically if resistance is detected during closing.
Flexible operating controls
Slim Control Panel (Plus/Premium), foot switches, control box, Bluetooth Remote Control, 3+1 buttons and wanderlead controls — pick the operating method that fits the application.
Cab control
In-cab control unit allows operation from the driver's cabin, reducing walking routes and improving efficiency.
QuickDown and software adjustments
QuickDown speeds up unloaded platform descent, and individual software adjustments tailor operation to the use profile.
Hydraulic oils
AeroShell Fluid oils factory-fitted for −40°/+40° conditions.
